Specifications
Conductor
Fully annealed tinned stranded copper per ASTM B-33
Insulation
Premium-grade, color-coded PVC
Temperature Range
-20°C to +105°C (-4°F to +221°F)
Voltage Rating
300 VAC
Compliances
• UL Style 1007 - 80°C
• UL Style 1569 - 105°C
• CSA TR-64 - 90°C
• Designed to meet UL VW-1 Vertical Wire Flame Test
• RoHS Compliant
• Internal wiring of electrical and electronic equipment
• Internal wiring of panels and meters
• Point-to-point wiring
J1128
Insulation Thickness
Gauge in mm
12 0.016 0.41
14 0.016 0.41
16 0.016 0.41
18 0.016 0.41
20 0.016 0.41
22 0.016 0.41
24 0.016 0.41
26 0.016 0.41
Outer Diameter
Gauge in mm
12 0.127 3.23
14 0.107 2.72
16 0.092 2.34
18 0.080 2.03
20 0.070 1.78
22 0.062 1.57
24 0.056 1.42
26 0.047 1.19
Gauge Stranding
12 65/30
14 41/30
16 26/30
18 16/30
20 10/30
22 7/30
24 7/32
26 7/34
Item# H20-09-500
