General Features:
Silver color
Based on the Wireless-N technology, data throughput is up to 3 times faster than 802.11g devices
Provides the highest data rate of up to 150 Mbps
Fully compatible with 802.11 b/g/n wireless devices
2.4 GHz frequency band
3 dBi Omni directional antenna
Stable wireless connection and high bandwidth enable you to enjoy the network applications without any interruption
Easy to setup, supports WPS (WiFi Protected Setup)
Bandwidth management features
Functions:
Supports AP, AP Client, Bridge, Bridge+ WDS and Universal Repeater modes
Port Triggering for special applications
DDNS and SIP
Virtual Server and DMZ hosting
MAC/IP filter and URL blocking
Static routing
UPnP architecture
VPN Pass-Through (IPSec/PPTP)
Schedule control
Management:
12-language User Interface
Supports Remote Management
Supports EZView Management
System Status and Security Log (Web Interface)
Firmware upgradeable
WAN:
Supports WISP connection mode
Supports RJ-45 cable/ xDSL modem
WAN protocol: PPPoE /Static IP/PPTP/Dynamic IP/L2TP/ Telstra Big Pond
Security:
NAT/NAPT IP Sharing
64/128-bit WEP Encryption and WPA-PSK, WPA2-PSK security
DHCP Server/Client
QoS for critical operations
SPI Anti- DoS Firewall
Output Power/Sensitivity Gain:
11n: 16 ±1 dBm, 11g: 16 ±1 dBm, 11b: 18 ±1 dBm
11n (40 MHz): -68 dBm, 11n (20MHz): -71 dBm, 11g: -74 dBm, 11b: -87 dBm
Memory:
4 MB NOR Flash
16 MB SDRAM
LEDs:
Power/WPS, WAN, WLAN, LAN 1 ~ 4
Interface:
One (1) 10/100 Mbps WAN port
Four (4) 10/100 Mbps LAN ports
WPS button
Reset button
Radio On/Off switch
12V DC power connector
Power Requirements:
DC 12V, 0.5A
Unit Dimensions:
1.25 x 7 x 4.3-inches (H x W x D, approximate)
