INFRARED EMITTING DIODE BI-DIRECTIONAL 950NM PO-2MW IR LED
Electro–Optical Characteristics: (TA = +25°C unless otherwise specified)
Parameter Symbol Test Conditions Min Typ Max Unit
Forward Voltage VF IF = 20mA – 1.2 1.4 V
Peak Forward Voltage VFM IFM = 500mA – 3.0 4.0 V
Reverse Current IR VR = 3V – – 10 µA
Terminal Capacitance Ct V = 0, f = 1MHz – 50 100 pF
Radiant Flux e IF = 20mA 0.7 1.0 2.0 mW
Peak Emission Wavelength λp IF = 5mA – 950 – nm
Half Intensity Wavelength ∆λ IF = 5mA – 45 – nm
Item# NTE30001
$3.13
Availability:
In stock
