LiteOn LTP2558AA-RA. Large, 2.4x1.5Inch Dot matrix, Red-Orange and Green LEDs. Gray face with white dots in off-state.
Liteon 5 x 8 Red Orange & Green Dot Matrix Display w/3mm Dots #LTP-2558AA
Item Description, Features, and Specifications:
This is a new 5 x 8 LED dot matrix array with 3mm diameter dots.
Each dot is capable of displaying red orange or green.
Specifications:
Forward voltage green: 2.1~2.6v DC @20mA / 3~3.7v DC @80mA
Forward voltage red orange: 2~2.6v DC @20mA / 2.6~3.4v DC @80mA
Cathode column, anode row
Average luminosity intensity both colors: 1500~4800 µcd
Overall dimensions: 37.9mm(1.492")W x 60.8mm(2.394")L x 8.9mm(0.35")H
Stackable horizontally
Compatible with USASCLL and EBCDIC codes
