Audio Matching Transformer Primary: 10K 10000 Ohms CT, Secondary: 10K CT Ohms 40mw 1.0 To 1.0 900-2713 W05

Mfr Tamura Series MET Turns Ratio - Primary: Secondary 1:1 Impedance - Primary (Ohms) 10kCT Impedance - Secondary (Ohms) 10kCT DC Resistance (DCR) - Primary 1kOhm DC Resistance (DCR) - Secondary 1.3kOhm Transformer Type Data/Voice Coupling Frequency Range 300Hz ~ 100kHz Frequency Response ±2dB Voltage - Isolation 500VRMS @ 30 Seconds Power Level 40mW Operating Temperature -20°C ~ 85°C Mounting Type Through Hole Size / Dimension 0.409" L x 0.310" W (10.40mm x 7.87mm)
