Philmore 30-18203 Mini Snap Action Switch, SPDT 10A Simulate Roller HIGHLY VS10N041C
SPECIFICATIONS:
Current Rating: 10A@ 125/250V AC
Initial Contact Resistance: 15 Meg ohm (Max.)
Insulation Resistance: 100 Meg ohm (Min.) at 500VDC
Dielectric Strength: 1000V AC 50/60 Hz for 1 Minute
Contact Material: Silver
Terminal Material: Brass - Silver Plate
Terminal Type: .250” Quick Connect
SPECIFICATIONS:
OF Max.: 115g
RF Min.: 14g
PT Max.: 3.7mm
OT Min.: 1.6mm
MD Max.: 1.2mm
OP: 18.7 + 1.2mm
Item# 30-18203B
$4.28
Availability:
In stock
- Buy 25 for $1.90 each and save 56%
- Buy 100 for $1.63 each and save 62%
